強固型標籤(ABP6923)
RFID Protocol: EPC Class1 Gen2, ISO18000-6C
Frequency: (US) 902-928MHz, (EU) 865-868MHz
Frequency: (US) 902-928MHz, (EU) 865-868MHz
規格說明
Functional & Specifications:
RFID Protocol: | EPC Class1 Gen2, ISO18000-6C |
Frequency: | (US) 902-928MHz, (EU) 865-868MHz |
IC type: | NXP UCODE 8 |
Memory: | EPC 128bits , USER 0bits, TID 96bits |
Write Cycles: | 100,000 times |
Functionality: | Read/write |
Data Retention: | 50 Years |
Applicable Surface: | Metal Surfaces |
Read Range : (Fix Reader) |
11m, (US) 902-928MHz 10m, (EU) 865-868MHz |
Read Range : (Handheld Reader) |
5.5m, (US) 902-928MHz 5.0m, (EU) 865-868MHz |
Physical Specification:
Size: |
69.0x23.0mm, Hole: D5.2mmx2 |
Thickness: | 7mm |
Material: | ABS+PC |
Colour: | White |
Mounting Methods: | Adhesive, Screw, binding |
Weight: | 10.8g |
Dimensions:
Environmental Specification:
IP Rating | IP68 |
Storage Temperature: | -40°С to +85°С |
Operation Temperature: | -25°С to +85°С |
Certifications: | Reach Approved, RoHS Approved, CE Approved, ATEX Approved. |
